Engine & Performance
Fuel Type
Diesel
Diesel / Petrol
Displacement
2,596 cc (2.6L)
1,997 cc (2.0L mStallion Turbo Petrol) / 2,184 cc (2.2L mHawk Diesel)
Engine Config
2.6L FM 2.6 CR CD 4-Cylinder Common Rail Turbocharged Diesel
2.0L mStallion Direct-Injection Turbo Petrol (200 PS & 380 Nm - Class Leading Petrol Power) / 2.2L mHawk Common Rail Turbo Diesel (185 PS & 450 Nm AT / 420 Nm MT / 156 PS on MX)
Drivetrain
4x4 with Shift-on-the-Fly Transfer Case (4H/4L) + Manual Mechanical Front & Rear Locking Differentials
Front-Wheel Drive (FWD) / All-Wheel Drive (AWD with Electronic On-Demand Torque Transfer on AX7/AX7L Diesel AT) + Multi-Drive Modes (Zip, Zap, Zoom, Custom on Diesel)
0-100
14.2 sec
8.8 sec (Petrol AT) / 9.2 sec (Diesel AT)
Top Speed
140 km/h
200 km/h
Brakes, Wheels & Suspension
Front Brakes
Disc (Front)
Ventilated Disc Brakes (Front 303 mm)
Rear Brakes
Drum (Rear)
Solid Disc Brakes (Rear 285 mm) - All 4 Disc Brakes Standard across all variants
Front Suspension
Independent Double Wishbone with Coil Springs & Anti-Roll Bar
Independent MacPherson Strut with Coil Spring & Frequency Selective Damping (FSD) + Stabilizer Bar
Rear Suspension
Rigid Live Axle with Coil Springs & Anti-Roll Bar
Multi-Link Independent Rear Suspension with FSD Shock Absorbers & Stabilizer Bar
Wheel Type
18-inch Diamond-Cut Alloy Wheels
18-inch Diamond-Cut Two-Tone Alloy Wheels (AX7/AX7L) / 17-inch Alloys (AX3/AX5)
Tyre Size
255/65 R18 All-Terrain Tubeless Radial
235/60 R18 Tubeless Radial
Spare Wheel
Tailgate Mounted Full Size Alloy Spare Wheel
Full Size 17-inch Spare Wheel under body
Dimensions & Capacities
Height
2,080 mm (with factory snorkel)
1,755 mm (with roof rails)
Wheelbase
2,825 mm (+425 mm wheelbase)
2,750 mm (Long wheelbase for spacious 3-row cabin)
Ground Clearance
233 mm
200 mm (Unladen SUV ground clearance; Water Wading Depth: 450 mm)
Kerb Weight
2,425 kg
1,760 kg - 1,960 kg
Boot Space
250-500 Litres (expandable with 3rd row folded)
450 Litres (3rd row flat) / 100L (all 3 rows up) / 800L (all rear seats folded flat)
Fuel Tank
63.5 Litres
60 Litres
Safety & ADAS
NCAP Rating
No crash-test rating has been published for this model.
Global NCAP (2021): 5 stars for adult occupants (16.03/17) and 4 stars for children (41.66/49). The test car had 2 airbags. It was tested under Global NCAP's older, less demanding rules.
Airbags
Dual Front Airbags
7 Airbags on AX7L (Dual front, front side thorax, full 3-row curtain, driver knee airbag) / 6 Airbags on AX7 / 4 Airbags on base
ESP/TC
Yes (ABS with EBD, Electronic TPMS with spare tyre sensor, Rear Parking Sensors)
Yes (Electronic Stability Program ESP with 11 Standard Safety Features: Roll-Over Mitigation, Hill Hold Control, Hill Descent Control, All 4 Disc Brakes with EPB & Auto Hold, Brake Disc Wiping)
ADAS
None
Level 2 ADAS (Advanced Driver Assistance System with 12 Autonomous Safety Features: Adaptive Cruise Control ACC with Stop & Go on AT, Autonomous Emergency Braking AEB for Vehicles/Pedestrians/Cyclists, Forward Collision Warning FCW, Lane Keep Assist LKA, Lane Departure Warning LDW, Smart Pilot Assist, High Beam Assist, Traffic Sign Recognition, Driver Drowsiness Detection)
Camera
Rear Parking Camera with Static Guidelines & Sensors
360-Degree Surround View 3D HD Camera with Blind View Monitor in Instrument Cluster & Front/Rear Parking Sensors
TPMS
Yes (TPMS)
Yes (Direct Active TPMS with individual tyre pressure & temperature readout)
ISOFIX
Yes (2nd row outer seats)
Yes (2nd row outer seats with ISOFIX)
Interior & Infotainment
Touchscreen
9.0-inch High-Definition Touchscreen Infotainment System
Dual 10.25-inch Integrated Curved Cinematic Screen Setup: 10.25-inch Touchscreen with Adrenox OS & Amazon Alexa Built-In
Digital Cluster
7.0-inch Digital Instrument Cluster with Speed, RPM & TPMS Readout
10.25-inch Full Digital High-Definition Driver Information Display with 3D Navigation Mirroring & ADAS Visualizer
CarPlay/Android Auto
Wireless & Wired Apple CarPlay & Android Auto
Wireless Apple CarPlay & Wireless Android Auto
Connected Tech
Bluetooth Handsfree & USB Connectivity
Mahindra Adrenox Connected Suite with 75+ Features, Alexa Voice Commands (including Hindi commands), Remote Engine Start with AC Pre-cool, E-Call SOS, Smartwatch App
Audio System
4-Speaker Audio System
Sony 12-Speaker Immersive 3D Custom Sound System with Subwoofer, Roof-Mounted 3D Speakers & 445W 12-Channel Amplifier with Sound Building Blocks
Sunroof
None
Panoramic Sliding Dual-Pane Glass Sunroof ('Skyroof' - Largest in Segment with One-Touch Operation)
Seat Features
7-Seater Layout with Bench 2nd Row and 3rd Row Captain Seats with Armrests
6-Way Power-Adjustable Driver Seat with Memory (3 Slots) & Welcome Retract + Front Row Ventilated Seats in Premium White Leatherette + 2nd-Row Captain Seats with Armrests
Climate Control
Manual Air Conditioning with Roof-Mounted 2nd & 3rd Row AC Vents
Dual-Zone Fully Automatic Climate Control (FATC) with Separate 2nd & 3rd Row AC Vents & Independent Blower Controller
Wireless Charger
Yes (Fast USB Charging Ports across all 3 rows)
Yes (Fast Qi Wireless Smartphone Charging Pad with Active Cooling)
Lighting & Exterior
Headlights
Full LED Round Headlights with Integrated LED DRL Rings
Full LED Clear-Vision Auto Booster Headlamps with Automatic High-Beam Activation above 80 km/h & C-Shaped LED DRLs
Tail Lights
Vertical LED Tail Lamps
Full LED Arrow-Shaped Tail Lamps with Sequential Dynamic Turn Indicators
Fog/DRLs
Front Bumper Fog Lamps with Cornering Function & Factory Snorkel (700 mm water wading)
Front Bumper LED Fog Lamps with Cornering Function, Smart Streamlined Flush Door Handles with Auto Pop-Out Function, Electronic Parking Brake (EPB) with Auto Hold & Shark Fin Antenna
Colours & Warranty
Standard Warranty
3 Years / 1,50,000 km (Includes 4 free services + 3-Year RSA)
3 Years / 1,00,000 km (Extendable up to 5 Years / 1,50,000 km via Mahindra Shield)
Service Interval
12 Months / 10,000 km (1st Service at 10,000 km / 150 days)
12 Months / 10,000 km
Features are what each maker lists for its top versions. "Not listed" means the maker's sheet does not mention it, not that the vehicle lacks it.
